Module with four individually configurable analog current outputs with HART. In addition to enabling the control of field actuators through the conventional 0-20mA signal, these outputs also allow HART communication with the instruments through the CPU's Ethernet port using an asset management tool with support for DTM technology.
04 saídas analógicas corrente 16 bits com HART
Single width module
Support different current ranges: 0 to 20 mA and 4 to 20 mA
HART protocol (4-20mA)
Individual configuration per output
Software-parameterizable filters
Galvanic isolation between inputs and internal logic
Surge protection
Open loop diagnostics
Display for module diagnostics and output status indication
Easy Plug System function
One Touch Diag function,
Electronic Tag on Display
MasterTool IEC XE is a complete tool for programming, debugging, configuring and simulating user applications. The software is based on the concept of an integrated tool, providing flexibility and ease of use, allowing users to program in six languages defined by the IEC 61131-3 standard.
Module with 16 isolated source/sink inputs for general use.
The NX1005 is a mixed module that offers 8 protected source-type digital outputs and 8 isolated source/sink-type digital inputs for general use. The NX1005 uses only one position in the Nexto Series rack and has exclusive features such as Electronic Tag on Display, Easy Plug System and One Touch Diag.
The NX1006 module offers 8 monitored sink-type digital inputs, occupying only one slot on the rack. These modules are used in fire detection and security systems, and are suitable for applications where a broken loop/line situation needs to be detected, that is, for continuous monitoring of the connection between the module and the field sensor.
Module with 16 protected source-type outputs for general use.
Module with 16 protected relay outputs, source type, for general use.
The NX2025 module offers 8 monitored source-type digital transistor outputs, occupying only one slot on the rack. These modules are recommended for applications where supervision of the electrical installation is necessary, indicating conditions of no load, broken wiring, short circuit, or overcurrent, featuring diagnostic functions to ensure the outputs' operation.
With a response time of 4 ms per cycle, the NX3003 is the best performing solution for the machinery market. The module has four fast inputs for encoder reading (unidirectional, bidirectional and quadrature) and four fast outputs for stepper motor control (PTO/PWM).
With high processing speed and large data storage capacity, the NX3004 CPU is suitable for small machines and systems that do not require a very complex automation structure.
In addition to high-speed processing (1000 contacts every 6 microseconds) and ample data storage capacity, the NX3005 CPU also features WebServer support, making it a great cost-benefit option for the demands of the sanitation, building automation, and general industry segments.
With high-speed processing, ample data storage capacity, bus expansion for up to 24 racks, and advanced real-time diagnostics, this is the most rugged processing unit in the NX Series.
The ruggedness and high performance of the 32-bit RISC Power PC processor make the NX3010 an ideal CPU for large machines and small to medium-sized systems.
With high processing capacity, bus expansion for up to 24 racks and advanced real-time diagnostics, the NX3020 CPU is ideal for medium and large automation systems
With high-speed processing, ample data storage capacity, bus expansion for up to 24 racks, and advanced real-time diagnostics, the most rugged processing unit in the series also offers support for redundancy.
The ruggedness and high performance of the 64-bit processor make the NX3035 an ideal CPU for systems that require high processing power and high availability.
The NX4000 module allows I/O modules to be easily distributed in the field, and can be used both as local I/O points (located next to the CPU module) and as remote I/O points, without any loss in performance.
The NX4010 module is used for redundant applications in half-clusters, where there is a need for high availability of the automation system. It is responsible for connecting the two half-clusters.
Ethernet module for applications that require more Ethernet interfaces than those provided by Nexto CPUs or in applications where there is a need for high availability of the automation system with the use of network redundancy
PROFIBUS-DP master module for use with Nexto Series CPUs. This module allows access to up to 3584 input bytes and 3584 output bytes, in addition to supporting redundancy for applications where high availability is expected.
Head-slave type device for MODBUS TCP networks, allowing the user to use all input and output modules of the Nexto Series.
Head-slave device for MODBUS TCP networks with integrated input and output interfaces, allowing the user to use all input and output modules of the Nexto Series.
Head-slave devices for PROFIBUS-DP networks, enabling the user to use all I/O modules of the Nexto Series.
Head-slave devices for PROFIBUS-DP networks, enabling the user to use all I/O modules of the Nexto Series.
Module with eight analog inputs that can be individually configured as voltage or current input. The product also provides different scales for both voltage and current inputs.
Module with eight thermocouple analog inputs that can be individually configured for different thermocouple types. The product also provides different temperature scales in degrees Celsius or Fahrenheit
Module with eight individually configurable analog current inputs with HART. In addition to enabling the reading of signals from field instruments through the conventional 0-20 mA signal, these inputs also allow HART communication with the instruments through the CPU's Ethernet port using an asset management tool that supports DTM technology.
Module with eight individually configurable analog inputs for reading RTD (Resistance Temperature Detectors) temperature sensors. The module allows the use of temperature scales in Celsius or Fahrenheit degrees and parameterizable filters that assist in the implementation of systems for industrial automation and process control.
Module with four analog outputs that can be individually configured as voltage or current output. This module also provides different scales for both voltage and current outputs.
Power supply with up to 30 W of power, supplied to the other modules through the racks. The module has an isolated 24 Vdc input with an internal protection fuse accessible through the side cover of the module.
The NX9000 (8-position backplane rack) is the perfect choice in applications with few or no local I/O points.
The NX9001 (12-position backplane rack) is a great solution for applications with few I/O points.
The NX9002 (16-position backplane rack) is an excellent choice for applications with higher I/O point density.
The NX9003 (24-position backplane rack) is the ideal choice for large applications and systems that demand a higher density of I/O points.
The NX9010 (8-position non-hot-swap backplane rack) is a suitable solution in machine applications.
The NX9020 (2-position panel mount base) is a suitable solution for applications that do not require I/O modules.
The NX9100 is a pair of side closures for the frame designed to protect the ends of the frame. This accessory is recommended for individual purchase.
The NX9102 is a connector cover for unused positions of the Nexto Series racks. This cover was specially developed to provide high protection for unused rack connectors.
Ethernet CAT5 communication cable with a length of 2 meters, equipped with male RJ45 connectors on both ends.
Ethernet CAT5 communication cable, with a length of 5 meters and male RJ45 connectors on both ends.
Ethernet CAT5 communication cable, with a length of 10 meters and male RJ45 connectors on both ends.
Connectors used in the Nexto Series input and output modules designed to facilitate the installation, maintenance, and replacement of modules.
Connectors used in the Nexto Series input and output modules designed to facilitate the installation, maintenance, and replacement of modules.
Connectors used in the Nexto Series input and output modules designed to facilitate the installation, maintenance, and replacement of modules.
Connectors used in the Nexto Series input and output modules designed to facilitate the installation, maintenance, and replacement of modules.
Connectors used in the Nexto Series input and output modules designed to facilitate the installation, maintenance, and replacement of modules.
Connectors used in the Nexto Series input and output modules designed to facilitate the installation, maintenance, and replacement of modules.
Connectors used in the Nexto Series input and output modules designed to facilitate the installation, maintenance, and replacement of modules.
Nenhum produto encontrado.
